Laptop showing the ArchiNova AutoCAD productivity systemThe full set

The whole kit on one machine: layers, sheets, and blocks ready to draft

1 / 8

The full drawing set

One payment. Yours to keep.

Stop rebuilding the same project setup.

One download replaces the layers, sheets, and blocks you redraw every time.

$25$199Save $174

Six files, one folder

Download the system — $25

14 days to open the files. Full refund if they are not a fit.

AMEX · MC · VISA · APPLE PAY · GPAY

Six things you still draw by hand

Redraw that setup one more time. Or stop.

Each card is a file in the folder. Together they are the $199 kit, inside one $25 payment.

CAD block library

200+ blocks, already at 1:1. Drop in the kitchen, the door, the tree — and keep the hour.

Metric and Imperial live in separate folders.

In the $25 folderEnlarge

ISO layer system

Names, colors, and pen weights are already decided. The next file opens on that list.

Matched to the plot style in the same folder.

In the $25 folderEnlarge

A1–A4 title blocks

A1 to A4. Project, date, number, and revision are already on the paper.

North arrows and graphic scales come with it.

In the $25 folderEnlarge

Dynamic doors & windows

Flip the swing. Stretch the width. Match the wall. That is a grip, not a redraw.

30°, 45°, 90°, sliding, bifold. Grips need full AutoCAD.

In the $25 folderEnlarge

CTB plot styles

Screen color already maps to the printed line. Walls stay heavy. Notes stay thin.

No plugin. Load the CTB and plot.

In the $25 folderEnlarge

Room & finish schedules

Door, window, finish, and material schedules, ready to fill and hand over.

The same tables in the drawing and in Excel.

In the $25 folderEnlarge

All six files. One download. Yours to keep.

Get the folder — $25

Who opens the file

Blank file. Again. Or this.

The architect

Open the project. The setup is already there.

Layers, the title block, and the pens are in the template. You draw the building.

The drafter

Insert the door. Plot the sheet.

Stretch the opening, load the pens, send the PDF. The printed line matches the screen.

The student

Hand in a set that looks like an office.

A real template. Not blocks copied off a forum the night before the review.

Layers, the template, title blocks, schedules, and standard blocks open in LT. Door and window grips need full AutoCAD. In LT those blocks still plot as clean geometry.

After you pay

You can draft the same day.

The Drive link is on the next screen, then in your inbox. Download it again whenever you need it.

What you unzip

ArchiNova_AutoCAD_System/

├── Metric/

├── Blocks/

├── Templates (.dwt)/

├── Title_Blocks/

├── Plot_Styles (.ctb)/

└── Schedules/

└── Imperial/

└── (same structure)

  1. 1

    Pick one unit system

    Open Metric or Imperial. Do not mix the two folders in one drawing.

  2. 2

    Start from the template

    The .DWT already has the layers, the title block, and the CTB attached.

  3. 3

    Insert, then plot

    Drop the blocks, fill the schedule, plot. The first PDF should read like an office set.

From the drawing board

What changed on the first project

Mariam Al-Rashidi

Senior Architect · Studio Lead · Dubai

Layers · sheets · CTB
Used it on a mixed-use submission. ISO layers loaded clean, the title block fields worked the first time, and the CTB matched our plot test without retuning pens.

James D.

Senior Architect · London

ISO layer system
Replaced a six-year layer list — A-WALL-OLD, A-WALL-OLD2 — with the template. On Monday the team stopped arguing about colors in the layer manager.

Ahmed Hassan

Architectural Technologist · London

Dynamic blocks · A3 sheets
Bought it for the blocks, kept it for the sheets. Door swings behave, sheet numbers update in paper space, and the PDFs look like a studio set. AutoCAD 2024 on a Mac.

Carlos M.

Architecture Studio Director · São Paulo

Office standard · plotting
It started as my own purchase and ended up on the server for eight drafters. Everyone uses the same Metric folder. Clients stopped emailing us to fix PDF lineweights.

Sophie L.

Junior Architect · Paris

Templates · block library
I was still piecing blocks together from forums. The first apartment layout had a title block, layers, and furniture in about 20 minutes — good enough to send.

Elena R.

Lead Project Architect · Milan

AutoCAD LT · schedules
Kitchen and door blocks are detailed, and the schedules open in LT. No dynamic grips there, but everything plots. The architectural side covers the work we do.

Before the $25

Versions, LT, license, and the refund.

Purchase & delivery

Yes. $25 once. No subscription and no renewal. The Google Drive link stays yours, and you can download the folder again later.

Software & files

License & team use

Refunds & support

Still unsure? Email hello@archinovalibrary.com before you pay. We reply on business days.

One payment · $25

Put a real template under the next drawing.

Drive link after payment · about 85 MB · client work included · 14-day refund

Layers, sheets, and blocks

$25 once · Drive link after payment

Download
